Cnc Lathe GRAZIANO MT 500 C
Sold
Cnc Lathe GRAZIANO MT 500 C
Location:Italy
Description
Cnc Lathe GRAZIANO MT 500 C, Swing over bed mm.550, Max turning diameter mm.400, Swing over cross slide mm.345, Center distance mm.1000, 20-4000 rpm, Turret 12 positions, 6 with driven tools, 34 Kw, cnc HEIDENHAIN PILOT, CE declaration, conveyor, tooling, available in our stock
Specifications
| Manufacturer | GRAZIANO |
| Model | MT 500 C |
| Year | 1998 |
| Condition | Buone |
| Serial Number | 928398 |
| Swing over bed mm. | 550 |
| Turning diameter mm. | 400 |
| Swing over cross slide mm. | 345 |
| Center distance mm. | 1000 |
| Motor power Kw | 34 |
| Spindle speed rpm | 20 - 4000 |
| Turret | 12 positions, 6 with driven tools |
| CE certificate | Yes |
| Cnc | HEIDENHAIN PILOT |
| Spindle attachment | ASA 8” |
| Bar capacity mm. | 74 |
| Chuck diameter mm. | 250 |
| Machine weight Kg | 6550 |
| Accessories | Tailstock, Conveyor, Fume extractor, Tooling |
